Composite panels COSMO® Frame - PVCR
PVC on both sides, XPS/PR core
Composite panels consisting of a PVC compact panel with a thickness of 2,0mm and a core of extruded polystyrene foam (XPS) and polyurethane foam (PUR).
TEST REPORTS
airborne sound insulation*
acc. EN ISO 717-1 Rw 36 (-1;-1) dB
ift 164 27961/1
airborne sound insulation**
acc. EN ISO 717-1 Rw 36 (-1;-1) dB
ift 164 32607/Z11
* panel thickness 58mm
** panel thickness 70mm
SPECIAL CHARACTERISTICS
- enhanced impact resistant
- weather resistant
- UV-resistant
- humidity resistant
- free of CFC and HCFC
- cold weldable with COSMOFEN SL-660.110
APPLICATION EXAMPLES
- window fillings
- door fillings
- balustrade panels
- partition walls
- trade fair construction
- façade panels
Technical information
Surface panels
PVC compact panels
Core materials
Polystyrene foam, extruded (XPS)
PUR recycling panel (RP)
Thermal conductivity
030 (XPS)
070 (PR)
Sound insulation value (dB)
36
Thickness of surface panels (mm)
2,0
Compressive strength (N/mm²)
0,30 (XPS)
24,0 (PR)
Screw-withdrawal resistance (N)
870 (PR)
Thickness swelling (%)
0,85 (PR)
Panel thickness (mm)/
U-value *
58/0,63 60/0,60 62/0,58
68/0,52 70/0,50 75/0,46
80/0,42
Standard dimensions (mm)
3000x1500, 4000x1500
Other dimension and variants upon request.
*calculated with λD according to DIN EN 13164, λB acc. to DIN 4108-4 upon request
