COSMO® façade elements VACUPA

High-effective thermal insulation vacuum composite panels

VACUPA is a COSMO® façade element with excellent heat insulation. It was deverloped with focus on a compact construction. Due to the profile construction thicker insulating elements are not frequently used.

Due to the excellent thermal insulation value of the vacuum core of the VACUPA panel, there is no need of a time-consuming edging of the sheets. The maximum heat protection in combination with the low depth makes this panel a unique alternative.

fire resistance rating
acc. DIN EN 13501-1
rating "E"


  • excellent thermal insulation value
  • diverse scope for design by using skin sheet of glass, aluminium or metal
  • high temperature resistance in the long term
  • low boundary effects / heat bridge
  • 8 - 10 times higher heat insulation compared to conventionally used mineral wool

easy processing and installation due to the huge space saving

  • window fillings
  • door fillings
  • balustrade panels
  • industrial door fillings
  • façade panels


Technical information

Surface panels
Optional ESG single pane safety glass, aluminium, steel, stainless steel, burled plates

Core material
Vacuum insulation consisting of inorganic substances

Thermal conductivity

Ψ 0,037 (W/m∙K) plywood profile
Ψ 0,032 (W/m∙K) PVC profile
Ψ 0,038 (W/m∙K) aluminium profile
ift 427 32301/2

Ψ 0,032 (W/m∙K) plywood profile
Ψ 0,038 (W/m∙K) PVC profile
Ψ 0,032 (W/m∙K) aluminium profile
ift 427 32301/1

Sound insulation values (dB)
35 (ift 161 26897/1)
39 (ift 161 26897/2)

Panel thickness (mm)/U-value
24/0,41   28/0,34   32/0,29

individually according to constructional requirements, fixed dimension
