Bonding of leaf-enclosing entrance door panels

For many years, in addition to the classic door designs with insert panel, the market of windows and doors has been offering the possibility of making leaf-enclosing door panels with attachment panel. This type of door design gains more and more acceptance in the market due to its attractive appearance, safety-related advantages, improved heat-resistance, as well as its less demand on care compared with the classical variants.

For the production of this kind of door 1- and 2-component STP- and PUR-based adhesives are used for gluing of top coats and section frames.

For these applications, Weiss offers the 2-C-STP construction adhesives COSMO® HD-200.101 and COSMO® HD-200.121 as a product solution with a system primer. Due to their characteristic properties as flexible, controllably curing hybrid adhesives, they have just turned out to be the optimal product option compared to 1-C adhesives.

Attachment panel (Exemplary design)

Section and top coat materials

  • Plastic materials (PVC white, PVC film, GRP and others)
  • Metals (aluminium blank/painted, steel blank, and others)
  • Inorganic, not metallic materials (ceramics)

Depending on the material, we recommend our activator COSMO® CL-310.110 for the preparation of bonding surfaces.

More details ...>


The solution: The controlled adhesive

2-C-STP Construction Adhesive COSMO® HD-200.101

  • Flexible, tension compensating 2-C-STP-adhesive
  • Controlled curing and process times (2C-technology)
  • Independent from air humidity and climate
  • No additional application of moisture required
  • H351 (R40) no marking required
  • Highly weather-resistant

>> Product details




The highly reactive one

2-C-STP Assembly Adhesive COSMO® HD-200.121

  •   Controlled process times
  •   Functional strength after 45 hours
  •   Very good dosing behaviour
  •   Very good weather-resistance
  •   High temperature acceptance

>> Product details




Other accessories for the gluing process





COSMO® CL-310.110

Activator

Activation of bonding areas before bonding with adhesives of the COSMO® HD product range

Details


COSMO® CL-300.150

Special cleaner

Non-dissolving, mild smelling special cleaner for powder-coated and anodised surfaces.

Details
